SPEC
| MODEL | グレーター |
|---|
| PRICE | 65,000円(税抜) |
|---|
| SIZE | S、M |
|---|
| COLOR | シルバー |
|---|
| SPEED | Single |
|---|
| FRAME | 6061 Alloy PG tubing |
|---|
| FORK | Charge Whisk、Steel |
|---|
| CRANKSET | Shield、42t |
|---|
| PEDALS | Wellgo Alloy trekking |
|---|
| FRT DER. | N/A |
|---|
| RR DER | N/A |
|---|
| SHIFTERS | N/A |
|---|
| REAR COGS | DNP 16t FW |
|---|
| RIMS | Charge Urban、700c |
|---|
| TYRES | Charge Coaster、700x32c |
|---|
| FRONT HUB | Shield、looseball |
|---|
| REAR HUB | Shield、looseball |
|---|
| BRAKES | Tektro BX1-V |
|---|
| BRAKE LEVERS | Promax BL-46 |
|---|
| BRAKE ROTORS F/R | N/A |
|---|
| HANDLEBAR | Shield Urban alloy |
|---|
| STEM | Shield、31.8mm |
|---|
| SADDLE | Charge Spoon |
|---|
| SEAT POST | Shield、2 bolt |
|---|
GEOMETRY
| Size
| S |
M |
|
|
|
| Seat Tube
| 432 |
482 |
|
|
|
| Actual Top Tube
| 522 |
534 |
|
|
|
| Effective Top Tube
| 545 |
560 |
|
|
|
| Stand Over
| ‐ |
‐ |
|
|
|
| Head Angle
| 70 |
71 |
|
|
|
| Head Tube
| 120 |
130 |
|
|
|
| Seat Angle
| 73.0 |
73.0 |
|
|
|
| Chainstay
| 435 |
435 |
|
|
|
| Wheel Base
| ‐ |
‐ |
|
|
|
| O.L.D
| 135 |
135 |
|
|
|
| BB Drop
| 69 |
69 |
|
|
|
| Fork
| 395 |
395 |
|
|
|
LINE UP
GRATER 3
130,000円(税抜)
GRATER 2
92,000円(税抜)
GRATER 1
66,000円(税抜)
GRATER
65,000円(税抜)
GRATER 1 Mixte
68,000円(税抜)
